Techno SPA, DC Diaphragm
Video

Techno SPA, DC Diaphragm

₦299,000.00

Techno China

1 In Stock

SPA DC Diaphragm Pump Diaphragm pump parts generally fall into two groups: those that transmit mechanical energy from the motor to the pump, and those that deliver energy to the fluid. A diaphragm pump converts the mechanical energy of a motor into the dynamic pressure of a fluid. Performance Range...
-
+
₦299,000.00
Add to wishlist

SPA DC Diaphragm Pump

Diaphragm pump parts generally fall into two groups: those that transmit mechanical energy from the motor to the pump, and those that deliver energy to the fluid. A diaphragm pump converts the mechanical energy of a motor into the dynamic pressure of a fluid.

Performance Range

  • Clean water without abrasive particles
  • Liquid temperature up to +40°C
  • Ambient temperature up to +40°C
  • Immersion depth from 0.5 m to 5 m
Model Power (kW) Flow (m³/h) Head (m) Outlet (inch)
SPA3-30/2-1.1 1.1 3 30 1½"
SPA3-45/3-1.3 1.3 3 45 1½"
SPA3-60/4-1.5 1.5 3 60 1½"
SPA6-28/2-1.1 1.1 6 28 2"
SPA6-39/3-1.5 1.5 6 39 2"
SPA6-50/4-1.8 1.8 6 50 2"
SPA6-65/5-2.2 2.2 6 65 2"

Application Fields

  • Agricultural irrigation and drainage equipment
  • Rural well water pumping and farmland irrigation
  • Garden watering, water spraying, and fish ponds

Features

  • High head, multi-stage pump
  • Compact design, easy to install and maintain
  • Two-year warranty subject to terms and conditions

Components & Materials

  • Cast iron pump body
  • SS304 motor casing
  • Aluminium impeller
  • 304 stainless steel welded shaft or CS45# shaft
  • Single phase with built-in thermal protector
